Trash Waste Bin (Green)

The 110mm All-Terrain Wheel w/6mm Adapter has a foam core and therefore does not require air. They grip well on hard smooth surfaces and are perfect for travel on un-even surfaces where you may have mulch, sand, dirt, or gravel. They are designed and manufactured by Studica to work with the Studica Robotics Building platform and will also work with other building sets.

Specifications:

• Diameter: 110mm
• Width: 45mm
• Inner diameter of wheel frame: 75mm
• Hexagon connector: 12mm
• Unit weight: 128g
• 6mm axle adopter

The 100mm (4") Flex Wheel can be used for intake systems and conveyors.

Specifications:

• Diameter:   100mm (4")
• Axial width:  25mm
• Hub:  1/2" Inner Hex
• Inner Material: Molded Plastic in Yellow
• Outer Material: TPU Polyurethane in Blue
• Outer Material Durometer: 50A
• Weight: 0.038kg
• Step File

The Studica Flat Beam is 3mm thick and 8mm wide. As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required. You can easily connect to other channel, extrusions, bushings, bearing, mounting brackets and more so you can quickly assemble and disassemble robots and automated systems.

Specifications:

• Material: 6061-T6 Aluminum
• Thickness - 3mm
• Width - 8mm
• Length - 288mm
• Step File

This set of 12 pieces includes,

• 2 x 20cm 22AWG Cables with Dupont TJC8 2.54mm 3 pin, female to female connectors
• 2 x 40cm 22AWG Cables with Dupont TJC8 2.54mm 3 pin, female to female connectors
• 2 x 60cm 22AWG Cables with Dupont TJC8 2.54mm 3 pin, female to female connectors
• 6 x 3pin Dupont male to male connectors

The Titan Cable Pack contains three cables. A 60cm CAN Wire for connecting the Titan Motor Controller to a CAN 2.0B capable device and two (idk the 50cm JST-VH to JST-VH cables for connecting 12VDC power to other devices such as the VMX or Servo Power Block.

• 2 - JST-VH to JST-VH cable
  • 50cm
• 1 - CAN Wire
  • 60cm

The 6mm diameter D -Shaft is made of stainless steel and is used throughout our building system as drive components. The D-Shaft profile is used with pulleys, gears and hubs when tightening the set screws and creating a non-slip connection.

Specifcation:

• Stainless Steel
• 432mm length
• 6mm OD
• 5.5mm to flat
• Step File
